The "UNIFI Specifications for Grid-Forming Inverter-Based Resources" document offers a detailed roadmap for integrating and operating grid-forming inverter-based resources (GFM IBRs) within modern power grids. Developed by the Universal Interoperability for Grid-Forming Inverters (UNIFI) Consortium in collaboration with leading institutions and supported by the U.S. Department of Energy's Solar Energy Technologies Office, this comprehensive guideline addresses the critical challenges posed by the increasing penetration of renewable energy sources. The document establishes interoperability standards, ensuring that GFM IBRs contribute to grid stability and can operate effectively across various systems and manufacturers, regardless of vendor-specific technologies.
Introduction: The Critical Role of Grid-Forming Inverters
As the grid transforms to integrate more solar and wind energy, traditional synchronous machines are increasingly being replaced by inverter-based resources (IBRs). Unlike conventional grid-following inverters, grid-forming inverters play a crucial role in maintaining grid stability by providing faster responses to voltage and frequency disturbances. However, the lack of standardized specifications for GFM technology across different manufacturers leads to inconsistent responses, raising concerns about grid reliability. The document provides much-needed uniform specifications to standardize operations, ensuring predictable performance in diverse grid environments.
1.1 Grid-Forming Controls
The document defines grid-forming controls in accordance with North American Electric Reliability Corporation (NERC) standards. GFM IBRs maintain a constant internal voltage phasor, allowing them to react almost instantaneously to grid disturbances—typically within 0-5 cycles. This immediate response ensures that the grid remains stable, especially during the most critical time following a disturbance. In contrast, grid-following inverters take longer to respond and rely on outer control loops to adjust to grid changes, making GFM IBRs a superior choice for dynamic grid environments. Modern GFM IBRs are also equipped to provide fast frequency response within 50 ms to a few seconds, helping to manage voltage and frequency variations.
1.2 Scope and 1.3 Purpose
The scope of the specifications covers a wide range of technologies, including battery storage, solar PV, wind turbines, HVDC converters, and more. These specifications apply to multiple scales of the electrical grid, from local microgrids to large-scale transmission systems. The main objective is to establish uniform technical standards for integrating and operating GFM IBRs, ensuring smooth and efficient operation regardless of the system size or type of energy generation.
1.4 Limitations
The document acknowledges that limitations may arise due to local grid conditions and hardware constraints. For example, certain performance expectations may need to be adjusted if an inverter's energy source (such as a battery or wind turbine) cannot fully meet the demand. In such cases, mutual agreements between system planners and manufacturers are advised to modify performance criteria, balancing hardware limitations with operational needs.
2 Universal Performance Requirements for GFM IBRs
Normal Operating Conditions (Section 2.1)
GFM IBRs are expected to autonomously support the grid under normal operating conditions. They must provide:
- Reactive power to stabilize voltage levels.
- Power sharing across other grid generation resources, ensuring equilibrium.
- Positive damping to prevent voltage and frequency oscillations, particularly in grids with low system strength as measured by metrics like short circuit ratio (SCR) and rate-of-change of frequency (ROCOF).
Abnormal Operating Conditions (Section 2.2)
GFM IBRs must demonstrate ride-through capabilities during grid disturbances, ensuring grid stability:
- They are required to inject up to 1.5 times their full-rated current for up to 2 seconds during symmetrical faults, adhering to their ISRC (inverter short-term rated current) limits.
- They must maintain balanced voltage during both symmetrical and asymmetrical faults.
- GFM IBRs must also modulate their active power output to aid frequency recovery and operate within the standards set by IEEE 1547-2018 and IEEE 2800-2022 for abnormal grid conditions like phase jumps and voltage steps.
3 Additional Capabilities and Considerations
In addition to universal performance requirements, the document outlines optional features that may be necessary for specific use cases:
Intentional Islanding (Section 3.1)
GFM IBRs are capable of operating in intentional electrical islands—isolated sections of the grid that operate independently. In these scenarios, GFM IBRs must maintain stable voltage and frequency, and the island must have sufficient generation and power transfer capability to ensure stability.
Black Start and System Restoration (Section 3.2)
Some GFM IBRs are designed to offer black start services, allowing them to help restore power following a blackout. They must handle inrush currents from transformers and motor loads during system restoration. Additionally, GFM IBRs should have programmable ramp-up voltage to mitigate inrush currents and ensure smooth system recovery.
Harmonic Regulation (Section 3.3)
GFM IBRs are expected to comply with voltage harmonic requirements and, in some cases, inject harmonic currents to reduce overall grid voltage harmonics.
Communication (Section 3.4)
Secure communication between GFM IBR plants and system operators is essential for managing grid operations, especially during disturbances. GFM IBRs must remain operational even if communication is delayed, ensuring stable performance during grid events.
Secondary Signal Response (Section 3.5)
GFM IBRs should be equipped to receive external control signals from system operators, enabling secondary control for voltage and frequency adjustments based on real-time setpoints.
4 Modeling and Documentation
Accurate modeling is critical to the integration of GFM IBRs into power systems. The document underscores the need for detailed electro-magnetic transient (EMT) models to simulate the behavior of GFM IBRs across a wide range of operating parameters. These models are essential for predicting how inverters will respond to various events and for ensuring they meet the specified performance requirements.
Conclusion
The UNIFI Specifications for Grid-Forming Inverter-Based Resources provide a robust framework for the successful integration of GFM IBRs into power systems of all scales. By setting clear and standardized performance requirements, the document ensures that these advanced inverters can operate reliably in a rapidly evolving energy landscape. As renewable energy becomes more widespread, these specifications will play a vital role in maintaining grid stability, supporting the adoption of sustainable energy resources, and ensuring the ongoing reliability of modern power grids.
Access the full document Here.
